Renishaw MODUS Description

Renishaw's MODUS software serves as a robust solution for 5-axis measurement tasks. Its customizable user interface facilitates the offline development of native DMIS programs, which can extract geometry, dimensions, and tolerance data from CAD files while providing complete simulation capabilities. The software is equipped with certified algorithms that ensure accurate feature measurement, construction, and part alignment. Users can create programs directly from CAD, allowing for on-screen verification of probe paths. Additionally, it enables users to define the CMM environment, fixture setup, and the positioning of the part, which allows for comprehensive simulation of the 5-axis measurement procedures. This functionality significantly reduces CMM downtime, as programs can be prepared in advance, often requiring minimal to no prove-out time. Moreover, MODUS boasts a wide array of reporting features, including traditional text reports that can be fully customized by the user. Enhanced graphical reporting options allow for results visualization in relation to the CAD model, incorporating tools like whisker charts and 3D form plots for various features, thus providing a detailed understanding of measurement outcomes. Ultimately, this software not only streamlines the measurement process but also enhances accuracy and efficiency in manufacturing.

Integrations

No Integrations at this time

Reviews

Total
ease
features
design
support

No User Reviews. Be the first to provide a review:

Write a Review

Company Details

Company:
Renishaw
Year Founded:
1973
Headquarters:
United Kingdom
Website:
www.renishaw.com/en/modus-metrology-software--10495

Media

Renishaw MODUS Screenshot 1
Recommended Products
Custom VMs From 1 to 96 vCPUs With 99.95% Uptime Icon
Custom VMs From 1 to 96 vCPUs With 99.95% Uptime

General-purpose, compute-optimized, or GPU/TPU-accelerated. Built to your exact specs.

Live migration and automatic failover keep workloads online through maintenance. One free e2-micro VM every month.
Start Free

Product Details

Platforms
Windows
Types of Training
Training Docs
Customer Support
Business Hours
Online Support
